BOOM LIFTS

BOOM LIFT 65' STICK 4x4 W/ 5'JIB

Where to find BOOM LIFT 65 STICK 4x4 W 5 JIB in Vancouver

Image for reference only
Actual item may look different
Click on image for larger view

Where to find BOOM LIFT 65 STICK 4x4 W 5 JIB in Vancouver Where to find BOOM LIFT 65 STICK 4x4 W 5 JIB in Vancouver

Click on above thumbnails for alternate view

Daily: $499.50

Weekly: $1,508.50

Monthly: $3,485.50

Quantity: for a period of
day(s)   week(s)   month(s)

Additional Information

  • DESCRIPTION
  • A 65 ft rough-terrain stick boom lift with jib for high-reach outdoor access, construction, industrial maintenance, structural work, and exterior building projects. The fleet includes models such as the JLG 660SJ, MEC 65-J, and Genie S-65, with working heights around 71 ft, strong horizontal reach, 500 lb platform capacity, and diesel-powered rough-terrain performance. The straight boom design provides long outreach, while the jib improves final platform positioning near the work area. Commonly rented by contractors for commercial construction, envelope work, steel access, signage, and large exterior maintenance projects throughout the Lower Mainland.
  • JLG
  • Model: 660SJ
  • Boom, Bucket, Loader, Platform, and Stick:
  • Horizontal Reach: 56.75 in
  • Maximum Platform Capacity: 500.0 lbs
  • Maximum Platform Height: 66.67 in
  • Number of Boom Sections: 3.0
  • Platform Rotation: 180.0 degrees
  • Platform Size: 36 X 96 in
  • Swing: 360.0 degrees
  • Drive:
  • Drive: 2WD
  • Travel Speed (Lowered): 4.25 mph
  • Engine:
  • Emissions Tier: Tier 4 Final
  • Engine: Vortec 3000 MPFI
  • Engine Manufacturer: GM
  • Horsepower: 82.0 hp
  • Power Mode: Hybrid
  • Fluid Capacities:
  • Fuel Tank Capacity: 40.0 gal
  • Hydraulic Tank Capacity: 32.0 gal
  • Performance:
  • Gradeability: 30.0 percent
  • Weights & Dimensions:
  • Axle Oscillation: 8.0 in
  • Ground Clearance: 9.625 in
  • Inside Turning Radius: 91.5 in
  • Operating Weight: 26650.0 lbs
  • Outside Turning Radius: 210.0 in
  • Overall Width: 98.0 in
  • Stowed Height: 101.0 in
  • Stowed Length: 402.0 in
  • Tailswing: 45.0 in
  • Wheelbase: 97.5 in
  • Wheels & Tires:
  • Tire Size: 39 X 15 X 2.25
  • Click here for JLG Operators Manual
  • MEC
  • Model 65-J Straight Boom
  • Heights:
  • Working Height* 71 ft.* 21.6 m*
  • Platform Height 65 ft. 19.8 m
  • Drive Height 65 ft. 19.8 m
  • Maximum Outreach 47 ft. 14.3 m
  • Turntable Swing 360° Continuous
  • Jib Range of Motion 135°
  • Platform Rotation 180° (90° each side)
  • Platform:
  • Total Lift Capacity Size & Capacity 500 lbs. 227 kg
  • Personnel Capacity 2
  • Platform Width 90 in. 2.3 m
  • Platform Depth 40 in. 1.0 m
  • Platform Entry 1 End Swing Gate, 2 Slide Bars
  • Dimensions:
  • Length-Stowed (Overall) 30 ft. 9.1 m
  • Width 98 in. 2.5 m
  • Overall Height 100 in. 2.5 m
  • Tailswing 51 in. 1.3 m
  • Weight** (Approximately) 19,850 lbs.** 9,000 kg**
  • Working Conditions:
  • Drive 4 Wheel Drive
  • Gradeability 45%
  • Ground Clearance 12 in. 30.5 cm
  • Breakover Angle 22°
  • Axle Oscillation 20° ( 10°)
  • Tires Solid Rough Terrain
  • Power 50 HP Kubota Tier 4 Final
  • Power Source:
  • Fuel Capacity 32 gal. 121 L
  • Hydraulic Oil Capacity 40 gal. 151 L
  • Movement:
  • Turning Radius (Inside) 78 in. 1.9 m
  • Drive Speed 4 mph 6.4 kph
  • Boom Lift Speed 55 Seconds
  • Boom Extend Speed 25 Seconds
  • Jib Lift Speed 20 Seconds
  • Important - MEC lifts must be on a hard level surface while elevated.
  • Meets or exceeds the requirements of ANSI A92.20 and CSA B354.6.
  • Specifications subject to change without notice. Contact your MEC distributor for detailed instructions on the proper use and maintenance of this equipment.
  • Click here for MEC Operators Manual
  • Genie
  • Model: S65
  • Working Height: 71 ft (21.64 m)
  • Platform Height: 65 ft (19.81 m)
  • Horizontal Reach: 56 ft 2 in (17.12 m)
  • Platform Capacity: 500 lbs (227 kg)
  • Platform Rotation: 160°
  • Turntable Rotation: 360° continuous
  • Power Source: Diesel
  • Drive: 4WD
  • Tires: Foam-filled (or RT-Lug, depending on the unit)
  • Gradeability: 45%
  • Travel Speed: 3.7 mph (5.95 km/h)
  • FAQ
  • Q: What is a 65 ft stick boom lift used for?
  • A: It is used for high-reach outdoor work where long horizontal outreach and direct elevated access are required.
  • Q: Why choose a stick boom instead of an articulated boom?
  • A: A stick boom is preferred when the job requires longer direct outreach, while an articulated boom is better for reaching over obstacles.
  • Q: Does this boom lift have a jib?
  • A: Yes this category includes 65 ft stick boom units with jib options for improved platform positioning.
