FORKLIFTS & TELEHANDLERS

TELEHANDLER 12,000LB 56' REACH


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

Daily: Request Quote

Weekly: Request Quote

Monthly: Request Quote

Quantity: for a period of

The JCB 512-56 is a heavy-duty, high-reach telehandler built for construction and industrial applications. It features a maximum lift capacity of (12,000lbs) (5,444kg), a maximum lift height of (56ft) (17.07m), and a maximum forward reach of (42ft) (12.80m).
Performance Specs
Max Lift Capacity: 12,000lbs
Lift Capacity at Max Height: 5,000lbs on stabilizers 4,000lbs on tires
Lift Capacity at Max Reach: 3,500 lbs on stabilizers
Max Lift Height: 56ft
Max Forward Reach: 42ft
Engine & Drivetrain
Horsepower: 74hp or 109hp depending on the specific engine configuration Tier3/Stage3
Transmission: 4-speed PowershiftSteering
Modes: 3 modes Two-wheel, Four-wheel, and Crab steer
Frame Sway (Leveling): +- 10
Dimensions & Weight
Operating Weight: 30,635lbs 13,900kg
Overall Height: 8ft 10in 2,692mm
Overall Width: 8ft 1in 2,471mm
Overall Length (to front of carriage): 21ft 7in 6,579mm
Ground Clearance: 1ft 5.5in 444mm
Outside Turning Radius: 14ft 1in 4,293mm
